BAND - MV - Electrical Tape - Self Amalgamating Tape - RUBAN-BLANC
BAND - MV - Electrical Tape - Self Amalgamating Tape - RUBAN-BLANC - 1
BAND - MV - Electrical Tape - Self Amalgamating Tape - RUBAN-BLANC - 1

BAND - MV - Electrical Tape - Self Amalgamating Tape - RUBAN-BLANC

Extreme Duty Self-Amalgamating Insulation Tape – RUBAN-BLANC provides one of the most versatile insulating, waterproofing, splicing, protecting, repairing and bonding solutions available on the market. Once stretched and overlapped the magic begins, as they amalgamate with themselves to deliver a highly flexible and conformable taylored rubber moulding. There are three types of rubber used in the EMAAR self-amalgamating tape range: Silicone, Polyisobutylene (PIB) and Ethylene Propylene (EPR). This helps provide the different product characteristics and properties required to deliver a suitable tape for either specialist or general purpose applications.

Share it:

Specifications

APPLICATIONS

  • For splicing and repair of power cables  up to 69kV and the insulation, waterproofing and protection of electrical components.
  • General purpose of protection,  waterproofing, sealing for industry and the home.
  • For repair of holes in pipes and hoses and the prevention of water ingress and corrosion in a wide variety of uses.

PRODUCT BENEFITS

Extreme Duty Self-Amalgamating Insulation Tape – RUBAN-BLANC come with a protective liner interleave which is easy to remove and the material doesn’t snap on extended elongation. EMAAR’s self-amalgamating tape range stands out from the competition as one of the easiest to work with, excellent performance and the essential addition to every toolbox. Some of the features and benefits of using EMAAR self-amalgamating tapes are:

  • Excellent physical and electrical properties with a high degree of stability under conditions of use.
  • The tape amalgamates rapidly when applied under tension to provide a void-free homogeneous wrapping
  • Compatible with a wide range of rubber and plastic dielectric cable insulation. These include polyethylene.
  • Excellent resistance to water and ozone.
  • The tape will remove cleanly when cut, allowing it to be used as temporary insulation or protection.
  •  Service temperature: -40°C to +100°C.
  • Supplied in an easy to handle and apply tape form. The product is interleaved with a disposable plastic liner.

PRODUCT PROPERTIES

Branding: EMAAR ENERGY

ASTM D4325-13:

  • Thickness: 0.01-in., 0.02-in., 0.03-in.
  • Length: 9-yd., 10-yd., 11-yd., 12-yd.
  • Width: 0.75-in., 1-in., 1.5-in., 2-in.
  • Tensile Strength: 1,069.86 psi
  • Elongation at break point: 877%
  • Durometer Hardness: 54 Shore A
  • Fusion: Pass
  • Bonding Strength: Pass
  • Dielectric Strength: ≥ 600 V/mil
  • Volume Resistivity: 1013 ohm-cm
  • Heat Ageing (130ºC within 168h): Pass
  • Ozone Ageing: Pass

- ASTM D4388-13:

  • Temperature Rate @ Normal: 90ºC
  • Temperature Rate @ Emergency: 130ºC
  • Temperature Rate @ Short-Cricuit: 250ºC
  • UV Ageing Resistance: Pass

- ASTM D1000-17:

  • Flammability: Pass

- ASTM ISO4892-2:

  • Xenon Ageing: Pass

RECOMMENDATIONS

Care should be taken to avoid direct contact between the tape and petroleum-type solvents and oils. Oils may affect the electrical properties of the tape.

The rolls should be stored flat on their cut edges in the original packaging. The product must be protected from dust, heat, moisture, direct sunlight and solvent fumes. Storage temperature between +10°C and +25°C.

Under these conditions, the storage life of the tape in a temperate climate will be at least five years.
